SCS series truck scale (loadometer)

The products all adopt the international advanced stainless steel column type digital weighing sensor and the new intelligent digital weighing instrument design manufacture full digital modular truck scale, the stainless steel column type digital weighing sensor USES the digital technology, can carry on the digital technology automatic compensation to the temperature coefficient, the nonlinearity, the lag and the creep and so on; The weighing instrument has high precision, strong function, convenient operation and rich interface, which can realize various functions such as accumulation, query, printing and digital uploading. The structure of the platform is welded with u-shaped cold-formed steel, which can meet the requirements of bearing capacity. Scale design modular, standardized, serialized, can be freely combined into a variety of specifications of the truck scale, scale surface by the domestic advanced large steel plate blasting pretreatment machine processing, corrosion performance leading domestic, can adapt to a variety of harsh environment. Widely used in metallurgy, mining, machinery, chemical industry, port and highway freight station and other industries, is an ideal vehicle material weighing equipment.

Optional parts for the whole system: printer, large-screen display, computer, weighing management software, anti-cheating automatic monitoring system and other optional parts to expand the corresponding required functions. Its use of advanced digital technology, the value and function of a comprehensive beyond the traditional analog truck scale, and analog electronic truck scale, it has the following advantages:

● high accuracy : up to 1/10000

● anti-remote control cheating : if the remote control is installed, the system will automatically detect and alarm prompt

● transmission distance : up to 200 meters (only 20-30 meters simulated)

● anti-rf interference : meets the requirements of OIML R76 for electromagnetic sensitivity, electrostatic discharge and pulse train interference

● long - term reliable : not affected by temperature changes and mechanical vibration and other aspects of the impact and not often adjust the Angle difference

● easy maintenance : if there is a problem with the sensor, it can be solved within 30 minutes (the simulation needs 4-12 hours)

Product model : scs-10 scs-20 scs-30 scs-50 scs-60 scs-80 scs-100 scs-120 scs-150 scs-200

Index value : 10, 10, 20, 20, 20, 20, 20, 50, 100

Sensor capacity : 10 10 20 30 30 30 30 30 40 50
